Mechanical data •Dimensions: 14*9.6*2.15mm •Weight: 0.5g
Features •Support GPS/GLONASS/Galileo/QZSS •Support EASYTM self-generated orbit prediction •Support EPOTM orbit prediction •Support AGPS •Support SBAS ranging (WAAS, EGNOS, GAGAN,MSAS) •Support Jamming Removing •Low-noise amplifier has been integrated
Interfaces •Serial interfaces UART •Digital I/O PPS 3D-FIX FORCE -ON •Protocols NMEA PMTK
Performance data •Receiver type 33tracking/99 acquisitionchannel GNSS receiver •Max. update rate 10Hz •Sensitivity1 Tracking: -165 dBm Reacquisition: -160 dBm Cold starts: -147 dBm •Time-To-First-Fix2 Cold starts: 28 s (typical) Warm starts: 26s Hot starts: <1s EPO Assist: 13s（CTTFF) • Accuracy Automatic Position3: 2.5m CEP Speed4: 0.1m/s •Operation temperature: -40℃~+85 ℃ Support product •SIM68 EVB KIT with USB V2.0 full speed interface
Electrical data •Power supply 2.8~4.3V •Backup power 2.0V~4.3V •Power consumption2 3.3V（typical） Acquisition 25mA Tracking 20mA Backup 14uA -------------- 1.Demonstrated on EVB KIT at library 2.All SV @ –130 dBm 3.50% 24 hr static, -130dBm 4.50%@
|
